TE 70-AVR rotary hammer

Very powerful SDS Max (TE-Y) rotary hammer for heavy-duty concrete drilling and chiseling, with Active Vibration Reduction (AVR)

Weight according EPTA-Procedure 01/2003 without battery: 8.3 kg
Single impact energy: 11.5 J
Hammer drilling diameter range: 12 - 150 mm

Customers also searched for SDS Max hammer drill.

Choose options

Pack size

1 pc

Product options

Quantity

Packs

Total Pieces

You can not see your company prices

Please Log in or register to see your company prices.

Discounted net

AUD 4,770.00

1 Piece

Technical Data

Weight according EPTA-Procedure 01/2003 without battery

8.3 kg

Single impact energy

11.5 J

Hammer drilling diameter range

12 - 150 mm

Optimum hammer drilling range

20 - 55 mm

Hammer drilling RPM

360 rpm

Full hammering frequency

2760 impacts/minute

Functionality

Active Vibration Reduction (AVR), Chiselling, Hammer drilling, Depth gauge

Triaxial vibration value for hammer drilling into concrete (ah,HD)

10.8 m/s² ¹

Dust removal system available

TE DRS-Y, TE DRS-D, TE DRS-BK

Triaxial vibration for chiselling in concrete

9.0 m/s² ²

Dimensions (LxWxH)

540 x 125 x 305 mm

A-weighted emission sound power level

113 dB (A) ³

A-weighted emission sound pressure level

105 dB (A) ⁴

According to the applicable product standard (see the Operating Instruction for more details)
According to the applicable product standard (see the Operating Instruction for more details)
According to the applicable product standard (see Operating Instruction for more details)
According to the applicable product standard (see Operating Instruction for more details)

Documents

pdf Material safety datasheet Hilti Grease (EN) [ 722.8 KB ]

Download

Features & Applications

Features

Highest productivity for a wide range of drilling and chiseling applications
Low contact pressure for high user comfort
Active Vibration Reduction (AVR) makes the tool less tiring to use – helping to increase daily productivity
Optional DRS-Y dust removal system collects up to 95% of dust
Ruggedly built for a long lifetime

Applications

Hammer drilling in concrete, masonry and natural stone using bits in the 12-150 mm diameter range
Drilling holes for heavy-duty anchors from 20-40 mm in diameter
Breaching and demolition using pointed and flat chisels
Drilling with high torque in wood and steel
Hammer drilling in concrete, masonry and natural stone using bits in the 1/2" - 6" diameter range
