MQB
Galvanised clamp for cross-connection of one MQ strut channel to another
- Material composition: S235JR - DIN EN 10025
- Surface finish: Indoor Coated - Electro galvanised
- Material thickness: 4 mm
Technical Data
Material composition
S235JR - DIN EN 10025
Surface finish
Indoor Coated - Electro galvanised
Material thickness
4 mm
Environmental conditions
Dry indoor conditions (C1) Indoor with temporary condensation (C2)
Documents
Features & Applications
Features
- Compatible with MQN-C push button channel connectors – for much faster, adaptable assembly
- Universal – complete many different applications using few parts
- Easy to use
- Suitable for various channel profiles
- Pushbutton connector takes up shear and tensile loads
Applications
- Cross-connection of two strut channels
- Recommended for use in dry, interior environments
For approval or certificate information, please see individual items.
